Triple lens camera drone
100 MP 4/3 CMOS Hasselblad camera 6K/60fps HDR video
1/1.3" & 1/1.5" large CMOS telephoto lenses
Infinity gimbal with 360° rotation for dynamic camera movement
51min Flight time
DJI 04+
10 bit HDR video transmission up to 30 km
Drone Takeoff WeightApprox. 1,063 g
Dimensions Folded (with propellers):257.6 × 124.8 × 106.6 mm (L × W × H)
Folded (without propellers):257.6 × 124.8 × 103.4 mm (L × W × H)
Unfolded (without propellers):328.7 × 390.5 × 135.2 mm (L × W × H)”
Drone Max. climb speed10 m/s (Sport Mode) 6 m/s (Normal Mode) 6 m/s (Cine Mode)
Drone Max. descent speed10 m/s (Sport Mode) 6 m/s (Normal Mode) 6 m/s (Cine Mode)
Drone Max. horizontal speed
At sea level, in still air: 25 m/s* (Sport Mode) 18 m/s (Tracking Mode)
At sea level, with a tailwind of 2 m/s, flying in the same direction as the wind. 27 m/s* (Sport Mode) 18 m/s (Tracking Mode)
* Measured in a wind tunnel test environment when the drone takes off from a height of 0 m and climbs vertically by 1.5 m in Sport Mode. The data is for reference only. Always pay attention to the reminders in the camera preview during flight.
Drone Max. take-off altitude6,000 m
Max. take-off altitude is 3,000 ms DJI Mavic 4 Pro Propeller Guards.
Drone Max. flight time 51 minutes
Drone Max. hover time 45 minutes
Drone Max. flight distance 41 km
Drone Max. wind speed resistance 12 m/s
Drone Max. tilt angle 35°
Drone Operating temperature -10 °C to 40 °C (14 °F to 104 °F)
Drone Global navigation satellite system GPS + Galileo + BeiDou
Mavic 4 Pro 512GB (Creator Combo)Drone Class C2 (EU)
512 GB (available storage space is approximately 460 GB)
Hasselblad camera
FOV: 72°
Format equivalent: 28 mm –
Aperture: f/2.0 to f/11
Focus: 2 m to ~
Medium telephoto lens
FOV: 35°
Format equivalent: 70 mm
Aperture: f/2.8
Focus: 3 m to ~
Telephoto
FOV: 15°
Format equivalent: 168 mm
Aperture: f/2.8
Focus: 3 m to ~
Hasselblad camera – Video
Normal:
100 – 12,800 (Normal)
400 – 6,400 (D-Log)
100 – 6,400 (D-Log M)
100 – 6,400 (HLG)
Slow Motion:
100 – 6,400 (Normal)
400 – 3,200 (D-Log)
100 – 3,200 (D-Log M)
100 – 3,200 (HLG)
Stills:
100 – 6,400 (25 Mpx)
100 – 3,200 (100 Mpx)
Medium telephoto and telephoto – Video
Normal:
100 – 12,800 (Normal)
400 – 3200 (D-Log)
100 – 3200 (D-Log M)
100 – 3200 (HLG)
Slow Motion:
100 – 6400 (Normal)
400 – 3200 (D-Log)
100 – 3200 (D-Log M)
100 – 3200 (HLG)
Still Image
100 – 6400 (12MP)
100 – 3,200 (48 Mpx and 50 Mpx)
Hasselblad camera
25Mpx frame: 1 / 16,000 – 16 s (over 2 s for simulated long exposure
100Mpx frame: 1 / 8,000 – 8 s
25Mpx Automatic exposure bracketing (AEB) / sequential shooting / timed: 1 / 16,000 – 8 s
100Mpx Automatic exposure bracketing (AEB) / sequential shooting / timed: 1 / 8,000 – 8 s
Medium telephoto
12Mpx frame: 1 / 16,000 – 8 s (over 2 s for simulated long exposure)
48Mpx frame: 1 / 8,000 – 2 s
12Mpx Automatic exposure bracketing (AEB)/sequential shooting/timed: 1/16,000 – 2 s
48Mpx Auto exposure bracketing (AEB)/sequential shooting/timed: 1/8,000 – 2 s
Telephoto
12.5Mpx shot: 1/16,000 – 8 s (over 1 s for simulated long exposure)
50Mpx shot: 1/16,000 – 2 s
12.5Mpx Auto exposure bracketing (AEB)/sequential shooting/timed: 1/16,000 – 2 s
50Mpx Auto exposure bracketing (AEB)/sequential shooting/timed: 1/16,000 – 2 s
Hasselblad camera: 12,288 × 8,192
Medium telephoto: 8,064 × 6,048
Telephoto: 8,192 × 6,144
Hasselblad camera
Single shot:25 MP, 100 MP
Automatic exposure bracketing (AEB): 25 MP, 3/5/7 shots in 0.7 EV increments; 100 MP, 3/5 shots in 0.7 EV increments
Burst shooting:25 MP, 3/5/7 shots; 100 MP, 3/5 shots
Time-lapse:25 MP, 1 (Mavic 4 Pro 512 GB)/2/3/5/7/10/15/20/30/60 seconds; 100MP, 2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB)/5 (Mavic 4 Pro 512GB)/7 (Mavic 4 Pro 512GB)/10/15/20/30/60 seconds.
Medium Telephoto
Single shot:12MP, 48MP
Auto Exposure Bracketing (AEB): 12MP, 3/5/7 shots in 0.7 EV increments; 48MP, 3/5/7 shots in 0.7 EV increments
Burst:12MP, 3/5/7 shots; 48MP, 3/5/7 shots
Time-lapse:12MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds; 48MP, 1 (Mavic 4 Pro 512GB)/2 (Mavic 4 Pro 512GB)/3 (Mavic 4 Pro 512GB) /5/7/10/15/20/30/60 seconds
Telephoto
Single shot:12.5MP, 50MP
Auto Exposure Bracketing (AEB): 12.5MP, 3/5/7 shots in 0.7 EV increments; 50MP, 3/5/7 shots in 0.7 EV increments
Burst:12.5MP, 3/5/7 shots; 50MP, 3/5/7 shots
Time-lapse:12.5MP, 1 (Mavic 4 Pro 512GB)/2/3/5/7/10/15/20/30/60 seconds; 50 Mp+C23x, 1 (Mavic 4 Pro 512 GB)/2 (Mavic 4 Pro 512 GB)/3 (Mavic 4 Pro 512 GB)/5/7/10/15/20/30/60 seconds.
Formats
JPEG
DNG (RAW)
H.264 ALL-I/H.265
Hasselblad camera
Medium Telephoto
Telephoto
* Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
** Recording frame rate. The corresponding video will be played back as slow motion video.
C25 Camera Video format MP4 (H.264 ALL-I/H.264 Standard/H.265 Standard)
Camera Max. video bit rate
H.264 Standard Bitrate: 90 Mbps
H.265 Standard Bitrate: 180 Mbps
H.264 ALL-I Bitrate: 1,200 Mbps
Camera Supported File System exFAT
Camera Color Mode and Sampling Method
Hasselblad CameraNormal Color:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
8-bit 4:2:0 (H.264 Standard)
HLG/D-Log M/D-Log:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
Medium TelephotoNormal Color:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
8-bit 4:2:0 (H.264 Standard)
HLG/D-Log M/D-Log:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
TelephotoNormal Color:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
8-bit 4:2:0 (H.264 Standard)
HLG/D-Log M/D-Log:
10-bit 4:2:2 (H.264 ALL-I)
10-bit 4:2:0 (H.265 Standard)
Only Mavic 4 Pro 512GB (Creator Combo) supports H.264 ALL-I recording.
Hasselblad camera: 1x to 2.5x
Medium telephoto: 2.5x to 6x
Telephoto: 6x to 24x”
Gimbal Stabilization 3-axis mechanical gimbal (pitch, roll, roll)
Gimbal Mechanical range
Pitch: -164° to 160°
Roll: -90° to 450°
Roll: -22° to 22°”
Gimbal Controllable range
Pitch: -90° to 70°
Roll: -40° to 400°”
Gimbal Max. control speed
Pitch: 100°/s
Roll: 100°/s”
Gimbal Angular vibration range “Hovering in still air: ± 0.001°
Normal mode: ± 0.003°
Sport mode: ± 0.005°
Shooting typeOmnidirectional binocular visual system supplemented with frontLiDARand infrared sensor at the bottom of the drone.
Frontal Sensing
Measurement range: 0.5 – 24 m
Detection range: 0.5 – 200 m
Effective Sensing speed: Flight speed ? 18 m/s
FOV: horizontal 180°, vertical 180°
Rear Sensing
Measurement range: 0.5 -22 m
Detection range: 0.5 – 200 m
Effective Sensing speed: Flight speed 18 m/s
FOV: horizontal 180°, vertical 180°
Side Sensing
Measurement range: 0.5 – 21 m
Detection range: 0.5 – 200 m
Effective Sensing speed: Flight speed 18 m/s
FOV: horizontal 180°, vertical 180°
Scanning Upper
Measurement range: 0.5 -18 m
Effective scanning speed: Flight speed 6 m/s
FOV: horizontal 90°, vertical 90°”
Scanning Lower
Measurement range: 0.5 – 17 m
Effective scanning speed: Flight speed ?6 m/s
FOV: horizontal 180°, vertical 180°
Scanning Operating environment
Forward, backward, left, right and up:
Surfaces with recognizable patterns, adequate light (lux > 0.1, city lighting).
Downward:
Surfaces with recognizable patterns, diffuse reflectance > 20% (e.g. walls, trees, people) and adequate lighting (lux > 0.1, urban environment).
Video transmission Live view quality
Remote control: 1080p/30fps, 1080p/60fps
Video transmission Operating frequency
2.4000-2.4835 GHz
5.170-5.250GHz
5.725-5.850GHz
Video Transmission Transmitter Power (EIRP)
2.4 GHz: < 33 dBm (FCC) < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (CE)
5.8 GHz: < 33 dBm (FCC) < 14 dBm (CE) < 30 dBm (SRRC)
Video Transmission Max. Transmission Distance(Unobstructed, Uninterrupted)
FCC: 30 km CE: 15 km SRRC: 15 km MIC: 15 km
Video Transmission Max. Transmission Distance(Unobstructed, with Interference)
Heavy Interference (Urban Landscape): Approx. 1.5 – 6 km
Medium Interference (Suburban Landscape): Approx. 6-15 km.
Low Interference (Suburban/Coastal): Approx. 15-30 km
Video Transmission Max. Transmission Distance(With Obstacles, with Interference)
Low Interference and Obstacles in the Form of Buildings: 0-0.7 km.
Low Interference and Obstacles in the Form of Trees: Approx. 0.7 – 4.5 km.
Video Transmission Max. download speed
O4+: 10 Mbps Wi-Fi 6: 80 Mbps
Video Transmission Lowest latency
Compatible with DJI RC 2/DJI RC Pro2 Remote Controller: approx. 130 ms
Video Transmission Antenna 6 antennas, 2T4R
Wi-Fi Protocol 802.11 a/b/g/n/ac/ax
Wi-Fi Operating frequency
2.4000-2.4835 GHz 5.725-5.850 GHz
Wi-Fi Transmitter Power (EIRP)
2.4 GHz: < 23 dBm (FCC) < 20 dBm (CE/SRRC/MIC)
5.8 GHz: < 23 dBm (FCC/SRRC) < 14 dBm (CE)”
Bluetooth Bluetooth protocol 5.1
Bluetooth Operating frequency “2.4000-2.4835 GHz
Bluetooth Transmitter Power (EIRP) < 10 dBm
Batteries Capacity 6,654 mAh
Batteries Weight Approx. 332 g
Batteries Nominal Voltage 14.32 V
Batteries Max. Charging Voltage 17.2 V
Batteries Battery Type Li-ion 4S
Batteries Chemistry LiNiMnCoO2
Batteries Energy 95.3 Wh
Batteries Charging Temperature 5 °C to 40 °C (41 °F to 104 °F)
Charging Time
Using the DJI Mavic 240W Power Adapter without other devices connected to the charger or
USB-C charging hub port: From 0% to 100%: Charging one battery takes approximately 51 minutes, three batteries take approximately 90 minutes (at 200–240 V input voltage) or approximately 110 minutes (at 100–127 V input voltage).
Using DJI 100W USB-C Power Adapter: From 0% to 100%: Charging one battery takes approximately 80 minutes. Charging via drone (maximum charging power 65W)
From 0% to 100%: 115 minutes
Battery Charging Hub Input
USB-C port: 5V to 20V, max. 5A
Mini SDC port: 11.2V to 17.6V, max. 15A”
Battery Charging Hub Output Battery port: 10V to 17.2V, max. 12 A
Battery Charging Hub Rated Power “USB-C port: support up to 100 W
Mini SDC port: support up to 240 W/15 A
Battery Charging Hub Charging Type “When used with DJI Mavic 240W Power Adapter: Support parallel charging of three batteries (The Parallel Charging Hub will prioritize the least charged battery and switch to parallel charging once all three batteries reach the same charge level).
When used with DJI 100W USB-C Power Adapter: Sequential charging of three batteries.
Battery Charging Hub Compatibility DJI Mavic 4 Pro Intelligent Flight Battery
